What if you could squeeze a large double-reversible tramway into the footprint of a much smaller single-haul system?  The city of Brest, France and Bartholet of Switzerland will open such a tram in October.  Because its two cabins are never on the same half of the line at the same time, the Téléphérique de Brest has only one dock at each end and cabins pass directly on top of one another near a 270-foot tall center tower. Other lifts have been built with zero-gauge sections before (notably in Caribbean rainforests) but never on this scale or for their entire length.  The new ropeway is also France’s first lift in a true urban environment.

Facing a need connect two points high over The Penfeld river in this Navy port, the City of Brest selected a ropeway instead of a massive bridge or expensive tunnel.  The government held a design competition in 2014 and selected the Swiss firm Bartholet Maschinenbau Flums (BMF) together with the French construction conglomerate Bouygues.  Fellow BMF Group subsidiary Gangloff supplied two ultramodern 60-passenger cabins.  The project cost €19 million versus an estimated €30 to 60 for a new bridge.  BMF also recently built two double-reversible tramways in Mexico.

The system has four track ropes, two haul rope loops and four drive motors. The cabins are hung like those on a funitel and can operate in winds up to 70 miles per hour.  Each loop is driven by two 135 horsepower motors but if one fails the loops can be mechanically connected and run using the remaining three motors to ensure near 100 percent uptime.  The slope length of the tramway is a short 1,352 feet with a line speed of 7.5 m/s.  The system will transport up to 1,220 commuters per hour in each direction starting in October.  Check out videos of system testing here.
